D66*165mm White LED Track Spotlights With PC Cover / Citizen COB Chip

D66*165mm White LED Track Spotlights With PC Cover / Citizen COB Chip
D66*165mm White LED Track Spotlights With PC Cover / Citizen COB Chip

Large Image :  D66*165mm White LED Track Spotlights With PC Cover / Citizen COB Chip Get Best Price

Product Details:
Place of Origin: Xiamen , China
Brand Name: LFL
Certification: CE,Rohs ,TUV ,SGS
Model Number: C58-20W
Payment & Shipping Terms:
Minimum Order Quantity: 200pcs
Price: 38USD$/pcs
Packaging Details: 1pcs per pack
Payment Terms: Western Union
Detailed Product Description
Voltage: 100-277V Power: 20W
CRI: 85,90,92,97 Material: Diecasting Aluminum + PC
Dimension: D66*165mm LED Chips: Citizen COB
Beam Angle: 15/24/38 Degree Warrenty: 5yrs
THD: <10%&15% Light Efficiency: 95-100lm/W
High Light:

black led track lighting

,

wall mounted track lighting

20W commercial track lighting CRI 90 upto high efficiency 100LPW CE,ROhs TUV certificate Citizen COB chips







his particular image of Impressive White Track Lighting Fixtures Track Lighting Fixtures Connectors And Accessories is a part of white track lighting australia, white track lighting fixtures, white track lighting kit, white track lighting uk, and just one of our Picture Collection we have to home lighting design in this site.





Model Number C58-20W
  20w
Input voltage AC200-240V/50-60Hz
Size(mm) D66 L165mm
Light efficient 90-100lm per watt actually test
LED brand Citizen/Cree/Bridgelux/Epistar
CCT 2700/3000/3500/4000/5000K
CRI 83/90/97Ra
SDCM <3
Beam angle 15/24/38
Driver used Tridonic/Osram//Lifud
Power factor >0.95
Power efficient 88-91%
THD <10/<15%
Dimmable Triac/0-10V
Material Dia-casting aluminum+PC lens
Housing color White/black/silver
Certification TUV/CE/SAA/RoHS/CB/ENEC
Test data IES/LDT/ Integrating sphere
Warranty 3/5years
IP 44

D66*165mm White LED Track Spotlights With PC Cover / Citizen COB Chip 0D66*165mm White LED Track Spotlights With PC Cover / Citizen COB Chip 1

Advantage

  • High Beam Intensity (16,000 CBCP Spot)
  • 85,90,92,97. CRI options,
  • Compatible with Gobal, Halo, Juno and Contech track systems
  • Energy Efficient (100 Lumens per Watt)
  • Long life (L70 at 50,000 hours) minimizes the need for maintenance
  • Heat dissipation and excellent thermal performance .
  • High luminous efficiency .the product cooling system designed guarantee internal led light source working stable .And the LED’s luminous flux and luminous efficiency has been significantly improved
  • CRI 80/90/97 are available. Use citizen that LM80 approved cob chips from Japan original, thermoelectric separation design, high reliability,light decline is small. long life span
  • Shape design concise and fluent, suitable for various environmental style collocation.

Instructions

  • On the BBL is for standard lighting.
  • Below the BBL .Special lighting for fresh food, fashion,furniture, jewelry lighting and so on.
  • We can make CRI 80/83/90/97,CCT2700/3000/3500/4000/5000/5700/6500k are available.

Applications

  • Retail
  • Accent and spot



Our Services

  • OEM & ODM are accepted.
  • Your inquiry related to our products will be replied within 24 hours.
  • Protection of your sales area, ideas of design and your private information.
  • Any suggestion or comment of our product or our service will be highly appreciated.
  • Ø Tech Support & After-sale E-mail: web@longingforlight.com.





Power and Size Available



Power/Watt Size G.W(Kg)/pc G.W/Carton (Kg) Pcs/Carton
12/15/20/25w 66*165mm 0.7Kgs 21.5Kg 32pcs
